OmniScan X4 64:128PR Phased Array & TFM Flaw Detector
Manufacturer:Evident Scientific
0.0(0 reviews)
Next-generation ultra-high-resolution Total Focusing Method (TFM/FMC) and Plane Wave Imaging (PWI) Phased Array Ultrasonic Testing flaw detector. Engineered for advanced weld integrity, hydrogen-induced cracking (HIC), and thick-wall pressure vessel diagnostic scanning under API 510/570 standards.
Technical Specifications & OEM Data
Equipment CategoryInstrument
ManufacturerEvident Scientific
Supported MethodsPAUT, TOFD, TFM/FMC, PWI, UT
Acoustic Channels64 Pulser / 128 Receiver PR Configuration
TFM Real-Time Image GridUp to 2048 x 2048 Pixel Resolution (120 FPS)
Imaging ModesTFM, FMC, PWI (Plane Wave Imaging), PAUT, TOFD, Conventional UT
Screen Display11.6-inch Ultra-Bright Anti-Glare WXGA Multi-Touch Screen
Enclosure ProtectionIP66 Dust & High-Pressure Water Jet Resistant Rugged Casing
Internal Data Storage128 GB Internal NVMe SSD (Expandable to 2 TB via USB-C)
Battery LifeDual Hot-Swappable Li-Ion Batteries (up to 8 Hours Continuous)
CertificationISO 18563-1 / EN 12668-1 Compliant (International Organization for Standardization)
CertificationASME Sec V Art 4 & 5 Qualified (American Society of Mechanical Engineers)
CertificationCE & MIL-STD-810G Shock Certified (US Department of Defense)
Official Product Demo & Field Video
External OEM video link (YouTube, Vimeo, Bilibili)
Need Immediate Off-The-Shelf Local Delivery?
Connect with official authorized distributors in your region for local currency proposals.
OEM Support & Calibration Hub
Access official software updates, manuals, and remote diagnostics.
Awards & Industry Honors
Red Dot Best of the Best Industrial Design Award (2024)
ASNT Technical Innovation Leadership Award (2025)
