Time-of-Flight Diffraction (TOFD)
Method Overview
Precision diffraction-based flaw sizing and monitoring, providing high-accuracy weld integrity assessments.
Core Method Specifications
Target Applications & Governing Standards
2 Scopes ConfiguredMethod Limitations & Operational Boundary Conditions
Critical physics limits, thermal envelopes, blind spots, and ASME Sec V / API procedural boundaries for TOFD.
Lateral wave transit time drifts with elevated temperatures, corrupting flaw depth calculations if uncompensated.
Lateral wave duration masks upper 2.0 mm to 4.0 mm of wall; backwall echo rings down over bottom 1.0 mm to 2.0 mm
Constant pressurized water delivery line to both transmitter and receiver wedges
Omnidirectional diffraction energy from crack tips; highly insensitive to defect tilt angles
- •OD Near-Surface Lateral Wave Blind Zone: Flaws in top 2-4 mm hidden behind the direct surface wave pulse
- •ID Backwall Dead Zone: Flaws within 1-2 mm of inner diameter obscured by high-amplitude backwall reflection pulse
- •Transverse cross-weld cracks parallel to sound beam axis generate minimal diffraction signals
Lateral wave straightening artifacts distorting depth readings near uneven plate root gaps
Mandatory tandem pairing: PAUT pulse-echo inspects OD/ID dead zones missed by TOFD
Rapid surface verification of OD weld cap and toe crack indications
